Starter System
17-1
17. Starter System
Service Information 17-1
Troubleshooting 17-1
Starter Motor 17-2
Starter Magnetic Switch 17-3
Service Information
General Safety
● The starter motor can be maintained without removing the engine from the vehicle.
Item Standard value Service limit
Starter motor brush length - 6.5mm (0.255)
Starter motor brush spring tension - 680g
Unit: mm(in)
Troubleshooting
Starter motor will not turn
● Battery discharged
● Faulty ignition switch
● Faulty starter switch
● Faulty starter magnetic switch
● Loosen or disconnected wire or cable
Starter motor turns engine slowly
● Low specific gravity
● Excessive resistance in circuit
● Binding in starter motor
Starter motor turns, but engine does not turn
● Faulty starter clutch
● Faulty starter motor gears
● Faulty starter motor or idle gear
Starter motor and engine turns, but engine does not start
● Faulty ignition system
● Engine problems
Specifications
17
