L. Crank Case Cover/Kick Starter/Continuously Variable Transmission
Tighten the L. crank case cover bolt.
Assemble the cooling hose to the cover.
Install the kick starter pedal and tighten bolts.
Torque value: 2.2kg-m (22N.m, 16ft-Ib)
Feed the DAELIM genuine oil to the cylinder
head cover.
7-3
Crank case cover
Kick starter pedal
