8. Generator/Starter Clutch
Service Information 8-1
Shroud 8-2
A.C Generator 8-2
R.Crank Case Cover 8-4
Starter Clutch 8-6
Service Information
General Safety
This section describes the removal and assembling of the A.C. generator.
For information on A.C generator inspection, refer to the section 15.
The charging system can be maintained without removing the engine.
Specifications
Item Standard value service Limit
Starter driven gear
O.D 39.622-39.635(1.5599 -1.5604) 39.53(1.556)
I.D 32.000-32.025(1.2578 -1.2588) 32.10(1.2618)
Reduction gear I.D 12.016-12.034(0.4723 -0.4730) 12.10(0.4756)
Reduction gear shaft O.D 11.966-11.984(0.4703 -0.4710) 11.97(0.4705)
Torque values
Fly wheel bolt 5.5kg.m(55N.m, 39ft-lb)
Starter clutch socket bolt 3.2kg.m(32N.m, 23ft-lb)
R. crank case cover bolt 1.1kg.m(11N.m, 8ft-lb)
Tools
Fly wheel puller
Fly wheel holder
Unit: mm(in)
