L. Crank Case Cover/Kick Starter/Continuously Variable Transmission
Installation
Remove the crank case gasket, and install a new
gasket and dowel pin.
L. Crank Case Cover
Removal
Loosen the kick starter pedal bolt.
Remove the kick starter pedal.
Remove the cover side cooling hose.
Loosen the L. crank case cover bolt, and remove
the cover.
Remove the gasket and dowel pin.
7-2
Crank case cover
Kick starter pedal
To Next Page
