Page #45 background imageLoading...
Page #45 background image
Fuel System
5-1
5. Fuel System
Service Information 5-1
Troubleshooting 5-2
Fuel Tank 5-3
Air Cleaner Removal 5-4
Carburetor 5-4
Pilot Screw Adjustment 5-9
Fuel Pump Inspection 5-9
Service Information
General Safety
WARNING
Gasoline is extremely flammable. Avoid fire in the work place, also paying particular attention to sparks.
Furthermore, the evaporated (gasified) gasoline is highly explosive. Work in a well-ventilated areas.
Exhaust gas contains poisonous substance. Do not keep engine running for a long period of time in a
closed, or poorly ventilated area.
CAUTION
Do not excessively bend or twist cable. Distorted or damaged cable may lead to mechanical malfunctions.
Pay particular attention to the position of O-ring. Replace with new ones when disassembled.
If it is desired to store a vehicle for a period longer than 1 month, drain gasoline out of the carburetor float
chamber. Gasoline left in the float chamber will be deteriorated causing the slow jet to be clogged with
deposits, and idling may become unstable.
Specifications
Fuel tank capacity: 7.5
Reserve fuel capacity: 1.2
Item Standard
Type/Throttle bore CV type (vacuum) 24.2mm
Model mark BDS 26 92 H1
Main jet No. 92.5
Pilot screw opening 3,1/4 returns
Pilot jet 17.5
Idling speed 1600100(rpm)
Throttle grip free play 2-6mm
Tool
Float level gauge
Carburetor
5
