Brake System
14-11
Inatall the brake hose to the master cylinder with
2 new sealing washers and the hose bolt.
Torque: 3.5kgf
··
m
Connest the brake stop switch wire.
Fill the brake fluid, and bleed air.
Install the rear handle cover.(4-8)
Install the front handle cover.(4-8)
Install the back mirror.
Front master cylinder
Rear master cylinder
Rear master cylinder
