L. Crank Case Cover/Kick Starter/Continuously Variable Transmission
Disassemble the kick starter driven gear.
Disassemble the kick starter idle shaft.
Kick Starter Inspection
Check the kick starter spindle for wear or
damage.
Check the return spring for defects or damage.
Check the kick starter spindle bushing and the
idle gearshaft assembly for damage.
7-5
Driven gear
Idle gear
OIL
