Dahua IPC-HFW2431T-ZS-S2 User Manual

Figure 4-85 Multicast
Step 2 Select the Enable check box, and enter IP address and port number.
Table 4-28 Description of multicast parameters
Parameter Description
Multicast Address
The multicast IP address of Main Stream /Sub Stream is 224.1.2.4
by default, and the range is 224.0.0.0–239.255.255.255.
Port
The multicast port of corresponding stream: Main Stream : 40000;
Sub Stream1: 40016; Sub Stream2: 40032, and all the range is
1025–65500.
Step 3 Click Save.
Results
In the Live page, select RTSP in Multicast, and then you can view the video image with multicast
protocol.
4.6.10 802.1x
Cameras can connect to LAN after passing 802.1x authentication.
Procedure
Step 1 Select Setting > Network > 802.1x.
Figure 4-86 802.1x
Step 2 Select the Enable check box, and then congure parameters.
Table 4-29 Description of 802.1x parameters
Parameter
Description
Authentication PEAP (protected EAP protocol).
Operation Manual
97
