Parameter Description
Sensitivity
Set the alarm-triggered sensitivity. The higher the sensitivity is, the
easier the alarm will be triggered.
Max Height
Set the maximum height of the people in detection area. The unit
is cm, and the range is 0–300.
Min Height
Set the minimum height of the people in detection area. The unit
is cm, and the range is 0–200.
Step 5 Set arming periods and alarm linkage actions. For details, see "5.1.1 Alarm Linkage".
Step 6 Click Save.
To view alarm information on the Alarm tab, subscribe relevant alarm event. For details,
see "5.1.2 Subscribing Alarm".
Results
You can view the queuing result on the Live page.
The queuing number and the stranding time of each target are displayed on the page.
Figure 5-69 Queuing result
5.12.4 Viewing People Counting Diagram
You can search and export the heat map and tracking map according to the set searching criteria.
This function is available on some sheye cameras.
Operation Manual
195
