Dahua NVR5464-4KS2-V2

User's Manual
86
Figure 3-7 Loosen screws
Step 2 Remove the cover in the direction of the arrow as shown in the figure below.
Figure 3-8 Remove cover
Step 3 Turn over the device, and align the HDD to the four holes of bottom panel, and then fix the
HDD with screws.
Figure 3-9 Align HDD
Step 4 Connect HDD to the device using data cable and power cable.
