Dahua NVR5464-4KS2-V2 - NVR21 HS-I;NVR21 HS-I2;NVR21 HS-P-I;NVR21 HS-P-I2;NVR21 HS-8 P-I;NVR21 HS-8 P- I2;NVR44-4 KS2;I;NVR44-16 P-4 KS2;I Series

User's Manual
10
Figure 2-9 Front panel
The NVR21-P-I/NVR21-P-I2 front panel is shown as below.
Figure 2-10 Front panel
The NVR21-8P-I/NVR21-8P-I2 front panel is shown as below.
Figure 2-11 Front panel
2.1.7 NVR21HS-I/NVR21HS-I2/NVR21HS-P-I/NVR21HS-P-
I2/NVR21HS-8P-I/NVR21HS-8P-I2/NVR44-4KS2/I/NVR44-16P-4KS2/I
Series
The figure is for reference only.
The NVR21HS-I/NVR21HS-I2/NVR21HS-P-I/NVR21HS-P-I2/NVR21HS-8P-I/NVR21HS-8P-I2/NVR44-
4KS2/I/NVR44-16P-4KS2/I front panel is shown as below.
Figure 2-12 Front panel
