User's Manual
444
6.4.5 Configuring Cluster Control
6.4.5.1 Cluster Control
Background Information
From
SETTING
>
Cluster Service
>
Cluster Control
, you can enable or disable cluster.
Figure 6-4 Start cluster
You can see the corresponding prompt if you successfully enabled cluster service.
6.4.5.2 Arbitrage IP
When there are only 2 devices in the cluster, a third-party device is required to determine whether
the main device is faulty, so arbitration IP must be set for the cluster to perform a normal
replacement operation. The arbitration IP can be the IP address of another device, computer or
gateway.
Procedure
Step 1 Select
SETTING
>
Cluster Service
>
Arbitrage IP
.
Figure 6-5 Arbitrage IP
Step 2 Configure the preferred and alternate IP.
Step 3 Click
OK
.
