User's Manual
150
Expanded PTZ Control Panel
On the basic PTZ control panel, click to open the expanded PTZ control panel to find more
options. See Figure 5-41.
Figure 5-41 Expanded PTZ control bar
●
The functions with buttons in gray are not supported by the system.
●
Right-click once to return to the page of PTZ basic control panel.
Table 5-14 PTZ functions
Icon Function Icon Function
Preset
Pan
Tour
Flip
Pattern
Reset
Scan
Click the
AUX Config
icon to open
the PTZ functions settings page.
AUX Switch
Click the
Enter Menu
icon to open
the
PTZ Menu
page.
5.6.7.3 Configuring PTZ Functions
5.6.7.3.1 Configuring Presets
Procedure
Step 1 On the expanded PTZ control panel, click .
