User's Manual
405
●
Click the drop-down list of the state; you can enable/disable holiday date.
●
Click to change the holiday information. Click to delete current date.
Step 5 Click
Next
to save settings.
5.15.2 Serial Port
After setting RS-232 parameters, the NVR can use the COM port to connect to other device to debug
and operate.
Procedure
Step 1 Select
MAIN MENU
>
SYSTEM
>
Serial Port
.
Figure 5-297 Serial port
Step 2 Configure parameters.
Table 5-85 Serial port parameters
Parameter Description
Function
Select serial port control protocol.
●
Console: Upgrade the program and debug with the console and
mini terminal software.
●
Keyboard: Control this Device with special keyboard.
●
Adapter: Connect with PC directly for transparent transmission of
data.
●
Protocol COM: Configure the function to protocol COM, in order to
overlay card number.
●
PTZ Matrix: Connect matrix control
Different series products support different RS-232 functions.
Baud Rate Select baud rate, which is 115200 by default.
