User's Manual
94
The following figure is for reference only.
Figure 3-26 Connect cables
Step 9 Put back the cover and fasten the screws on the rear panel to complete the installation.
Figure 3-27 Fasten screws
3.3.5 NVR608-64-4KS2/NVR608-128-4KS2/NVR608H-32-
XI/NVR608H-64-XI/NVR608H-128-XI Series
Procedure
Step 1 Unlock the lock on the front panel.
