User's Manual
72
Icon Name Function
MIC OUT Audio output port
Audio output port. It is to output the analog
audio signal to the devices such as the sound
box.
●
Bidirectional talk output.
●
Audio output on 1-window video
monitor.
●
Audio output on 1-window video
playback.
GND Ground end.
2.2.31 NVR54-EI/NVR54-16P-EI/NVR58-EI/NVR58-16P-EI/NVR54-
XI/NVR-58-XI Series
The NVR54-EI series rear panel is shown as below.
Figure 2-110 Rear panel
The NVR58-EI series rear panel is shown as below.
Figure 2-111 Rear panel
The NVR54-16P-EI series rear panel is shown as below.
Figure 2-112 Rear panel
The NVR58-16P-EI series rear panel is shown as below.
