User's Manual
352
Table 5-70 Alarm center parameters
Parameter Description
Protocol Type Select a protocol type.
Server Address
The IP address and communication port of the PC installed with alarm
client.
Port
Auto Report Plan Select time cycle and specific time for uploading alarm.
Step 4 Click
Apply
.
5.11.16 Register
You can register the Device into the specified proxy server which acts as the transit to enable the
client software to access the Device
Prerequisites
●
The proxy server has been deployed.
●
The Device, the proxy server and the device running the client software are on the same network.
Procedure
Step 1 Select
Main Menu
>
NETWORK
>
Register
.
Figure 5-239 Register
Step 2 Click to enable the function.
Step 3 Configure the parameters.
