User's Manual
184
Parameter Description
Resolution
Select resolution for the video.
The maximum video resolution might be different depending on your
device model.
Frame Rate (FPS)
Configure the frames per second for the video. The higher the value is,
the clearer and smoother the image will become. Frame rate changes
along with the resolution.
Generally, in PAL format, you can select the value from 1 through 25; in
NTSC format, you can select the value from 1 through 30. However, the
actual range of frame rate that you can select depends on the
capability of the Device.
Bit Rate Type
●
CBR
(constant bit rate): The bit rate changes slightly around the
defined value. We recommended selecting
CBR
when there might
be only small changes in the monitoring environment.
●
VBR
(variable bit rate): The bit rate changes with monitoring
scenes. Select variable stream when there might be big changes in
the monitoring environment.
●
ABR
(average bit rate): When selecting
ABR
, you need to configure
Max Bit Rate
and
ABR
.
The connected camera needs to support the average bit rare.
Quality
The bigger the value is, the better the image will become.
This parameter is available if you select
VBR
as
Bit Rate Type
.
I Frame Interval The interval between two reference frames.
Bit Rate (Kb/S)
●
Main stream: The higher the value, the better the image quality.
●
Sub stream: For constant stream, the bit rate changes near the
defined value; for variable stream, the bit rate changes along with
the image but the maximum value still stays near the defined
value.
Step 3 Click
More
.
