User's Manual
70
Figure 2-108 Rear panel
Table 2-44 Ports
No. Name No. Name
1 Power Input 2 Alarm In/Out
3 Network Port 4 USB Port
5 eSATA Port 6
HDMI Port
High-definition decoding card is not
installed in standard hardware
configuration, you can purchase as
needed.
7 VGA Port 8 AUDIO IN, RCA Connector
9 AUDIO OUT, RCA Connector 10 RS-232 Port
