Pre-Installation Information
■  Beforebeginninginstallation,pleasereadthispublicationinits
entirety.
■  Directionsgiveninthisbulletinforrightandleftsidesassumea
position facing the indoor side of the unit ventilator.
■  Beforebeginninginstallation,ifprovided,removetheprotective
plasticlmcoveringtheunitpaintedpanels.
Plastic packaging is a suffocation hazard, dispose of properly. Keep
away from children.
Safety
Follow all safety codes. Wear safety glasses and work gloves.
Useaquenchingclothforbrazingoperations.Haveare
extinguisher available. Follow all warnings and cautions in these
instructions and attached to the unit. Consult applicable local
building codes and National Electrical Codes (NEC) for special
requirements.
Recognize safety information. When you see a safety symbol on
the unit or in these instructions, be alert to the potential for
personal injury. Understand the meanings of the words DANGER,
WARNING,andCAUTION.DANGERidentiesthemostserious
hazards that will result in death or severe personal injury;
WARNING means the hazards can result in death or severe
personalinjury;CAUTIONidentiesunsafepracticesthatcan
result in personal injury or product and property damage.
Improper installation, adjustment, service, maintenance, or use
cancauseexplosion,re,electricalshock,orotherconditions
which may result in personal injury or property damage. This
product must be installed only by personnel with the training,
experience, skills, and applicable licensing that makes him/her “a
qualiedprofessionalHVACRinstaller.”
Make sure lifting equipment can handle the weight of the unit
safely. Personal injury may result if improper lifting and moving
methods are used. (See table 2, page 3 for approximate shipping
weights)
Use 72" length forklift tines, short tines will damage the unit
bottom. Improper handling can damage internal components.
Do not stand the unit on end or stack (see gure 2 & 3)
Model AV Floor Unit Ventilator Installation
Models AVV, AVR, AVS, AVB, and AVR
Receiving & Handling
This product was carefully packed and thoroughly inspected
before leaving the factory. Responsibility for its safe delivery was
assumed by the carrier upon acceptance of the shipment. Claims
for loss or damage sustained in transit must therefore be made
upon the carrier, as follows:
Visible Loss or Damage
Any external evidence of loss or damage must be noted on the
freight bill or carrier’s receipt, and signed by the carrier’s agent.
Failure to adequately describe such external evidence of loss or
damage may result in the carrier’s refusing to honor a damage
claim.Theformrequiredtolesuchaclaimwillbesuppliedbythe
carrier.
Concealed Loss or Damage
Concealed loss or damage means loss or damage which does not
become apparent until the product has been unpacked. The
contents may be damaged in transit due to rough handling even
though the carton may not show external damages. When the
damage is discovered upon unpacking, make a written request for
inspectionbythecarrier’sagentwithinfteen(15)daysofthe
delivery date. File a claim with the carrier since such damage is the
carrier’s responsibility.
Storage
If equipment is stored for any length of time before installation, it should
remain in its shipping packaging in a clean, dry, climate controlled area.
Lifting Unit
A forklift or other lifting device is needed to install this product.
Figure 1 - Data Plate Location
Figure 2 - Stack Units Maximum 2 High as Shown
2 high
Correct
Incorrect
4'
6'
Figure 3 – Forklift Lifting Requirements
Lifting Points
WARNING
CAUTION
WARNING
