Daikin AVS - Unit Configuration Type an; Unit Configuration Type AK; Unit Configuration Type AP

IM 817-4 Page 9 of 60
Figure 15 – The 21
7
/
8
” (556mm) Deep Full Adapter Back Unit with
Closed Pipe Tunnel, Ducted with Top Intake
Figure 16 – 21
7
/
8
" (556mm) Deep Partial Adapter Back Unit with Open
Pipe Tunnel
Intake Louver
Not More
Than 12"
Unit Conguration Type AP
Unit Conguration Type AK
Figure 13 - 21
7
⁄
8
" (556mm) Deep Full Adapter Back Unit With
Standard Louver Application
Figure 14 - 21
7
⁄
8
" (556mm) Deep Full Adapter Back Unit with High
Louver Application
Not More
Than 28"(711mm)
Unit Conguration Type AN
Louver
Piping
Important: Gasket sealing
surface is required.
Lintel
(By Others)
Piping
Floor Line
Sealed Cement
Mortar;
Pitch Away From Unit
Important: Gasket sealing
surface is required.
Louver
Lintel (By Others)
Piping
Piping
Important: Gasket sealing surface is required.
Piping
Piping
Important: Gasket sealing
surface is required.
Louver Installation With Typical Unit Congurations
Lintel
(By Others)
Gasket Seal
Intake Louver
Piping
Piping
Window Sash
“Goose Neck”
Insulated Duct (By Others)
Duct Collar (By AAF)
Note:
Arrangement AB with full metal back panel, similar to
conguration type AN. (Outside air opening to be cut
and sealed by others.)
Floor Line
Floor Line
Floor Line
1"
(25mm)
1"
(25mm)
Sealed Cement
Mortar;
Pitch Away
From Unit
Sealed Cement
Mortar;
Pitch Away
From Unit
