Restrictions in Continuous Installation
In case where several devices are set up and installation inside the power board is carried out, each equipment installation
spaceandspacebetweenthewallsurfaceandthisequipmentshouldbeleftatleastasshownbelow.
40
80
325
40
140
40
40
DEC101A51 DEC101A51
DEC101A51 DEC101A51
(To Remove Front Panel:)
“1.5.4 Electric Wiring Work and Initial Setting” shouldbeperformedwiththefrontpanelremoved.Thefrontpanelcan
beremovedbydetaching2frontpanelscrewsshowninthefigureaboveandslidingitlightlytotheupperside.Upon
completionofallwiringconnectionsandsettingoperations,closethefrontpanelasitwasandscrewitfirmly.
Unit (mm)
FixtheDEC101A51firmlywith
the installation screws (M4)
