Daikin FT25DVM Service Manual

Si01-501 Specifications
Specifications 9
50Hz 230V
Note:

MAX. interunit piping length: 25m

MAX. interunit height difference: 15m

Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m

The data are based on the conditions shown in the table below.
Models
Indoor Units FT25DSG FT35DSG
Outdoor Units R25DSG R35DSG
Capacity (Rated)
kW 2.65 3.7
Btu/h 9,000 12,600
kcal/h 2,270 3,180
Moisture Removal L/h 1.2 1.9
Running Current (Rated) A 4.09 5.23
Power Consumption (Rated) W 850 1,150
Power Factor % 90.4 95.6
COP (Rated) W/W 3.12 3.22
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ12.7 φ12.7
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FT25DSG FT35DSG
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 8.8(311) 11.0(388)
M 7.4(261) 8.9(314)
L 5.9(208) 6.8(240)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 40
Speed Steps 5 Steps, Auto 5 Steps, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current A 0.16 0.18
Power Consumption W 35 40
Power Factor % 95.1 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L dBA 36/28 42/31
Outdoor Units R25DSG R35DSG
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Rotary Type Hermetically Sealed Rotary Type
Model RC30BV1R2T RH207VHST
Motor Output W 700 1,000
Refrigerant
Oil
Type SUNISO 4GSD. I. DIAMOND MS56
Charge L 0.4 0.52
Refrigerant
Type R22 R22
Charge kg 1.25 1.15
Air Flow Rate
m³/min 28.5 28.5
cfm 1,006 1,006
Fan
Type Propeller Propeller
Motor Output W 27 27
Running Current (Rated) A 3.93 5,05
Power Consumption (Rated) W 815 1,110
Power Factor % 90.2 95.6
Starting Current A 20 23
Dimensions (H×W×D) mm 540×750×270 540×750×270
Packaged Dimensions (H×W×D) mm 609×940×360 609×940×360
Weight kg 33 38
Gross Weight kg 37 42
Operation Sound dBA 48 48
Drawing No. 3D049520 3D049521
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
5.0m
