Daikin FT25DVM Service Manual

Specifications Si01-501
10 Specifications
50Hz 230V
Note:

MAX. interunit piping length: 30m

MAX. interunit height difference: 15m

Amount of additional charge of refrigerant for piping length exceeding 10m : 20 g/m (50class), 50g/m (60 class)

The data are based on the conditions shown in the table below.
Models
Indoor Units FT50DSG FT60DSG
Outdoor Units R50DSG R60DSG
Capacity (Rated)
kW 5.3 5.9
Btu/h 18,090 20,140
kcal/h 4,560 5,070
Moisture Removal L/h 2.9 3.9
Running Current (Rated) A 7.31 8.0
Power Consumption (Rated) W 1,650 1,800
Power Factor % 98.1 97.8
COP (Rated) W/W 3.21 3.28
Piping
Connections
Liquid mm φ 6.4 φ 9.5
Gas mm φ15.9 φ15.9
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FT50DSG FT60DSG
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 18.5 (653) 17.9 (632)
M 15.1 (533) 15.0 (528)
L 11.9 (420) 12.4 (437)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current A 0.18 0.22
Power Consumption W 40 50
Power Factor % 96.6 98.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L dBA 45/41/35 46/42/37
Outdoor Units R50DSG R60DSG
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Rotary Type Hermetically Sealed Swing Type
Model RC60V1TNRT 2YC45ZXD
Motor Output W 1,500 1,900
Refrigerant
Oil
Type SUNISO 4GSD. I. SUNISO 4GSD. I.
Charge L 0.85 0.75
Refrigerant
Type R22 R22
Charge kg 1.35 1.70
Air Flow Rate m³/min (cfm)
H 40.0 (1,412) 51.5 (1,818)
L — (—) 41.5 (1,465)
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 7.13 7.78
Power Consumption (Rated) W 1,610 1,750
Power Factor % 98.2 97.8
Starting Current A 33.5 8.0
Dimensions (H×W×D) mm 685×800×300 735×825×300
Packaged Dimensions (H×W×D) mm 732×955×390 784×960×390
Weight kg 49 54
Gross Weight kg 54 59
Operation
Sound
H dBA 54 52
Drawing No. 3D048631 3D048630A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
