Specifications Si18-201
48 Specifications
1.5.2 Heat Pump
"
""
"
Wall Mounted Type
★
Refer to Engineering Data Book.
"
2.5kW Class · 3.5kW Class
60Hz 220V
Model
FTX25JAVET FTX35JAVET
Cooling Heating Cooling Heating
Rating Capacity kW 2.5 3.4 3.5 4.2
Front Panel Color Almond White
Air Flow Rates
m³/min
H 7.5 8.8 7.8 8.7
M 6.4 7.5 6.7 7.4
L 5.4 6.2 5.5 6.2
cfm
H 265 311 275 307
M 226 265 237 261
L 191 219 194 219
Fan
Type Cross Flow Fan
Motor Output W 18
Speed Steps 5 Steps and Auto
Air Filter Removal / Washable / Mildew Proof
Running Current
★
(Rated) A 0.21
Power Consumption
★
(Rated) W 45
Power Factor
★
% 97.4
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185
Package Dimensions (W×D×H) mm 834×325×258
Weight kg 7.5
Gross Weight kg 11
Operation Sound dBA
H37373838
M34333535
L30303231
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
Drawing No. 3D031681 3D031682
"
5.0kW Class · 6.0kW Class
60Hz 220V
Model
FTXD50JVET FTXD60JVET
Cooling Heating Cooling Heating
Rating Capacity kW 5.0 6.5 6.0 7.2
Front Panel Color Almond White
Air Flow
Rates
m³/min
H 12.9 15.7 13.6 17.2
M 11.4 13.4 12.0 14.4
L 9.9 11.0 10.4 11.7
cfm
H 455 554 480 607
M 402 473 424 508
L 349 388 367 413
Fan
Type Cross Flow Fan
Motor Output W 54
Speed Steps 5 Steps and Auto
Air Filter Removal / Washable / Mildew Proof
Running Current
★
(Rated) A 0.19 0.18 0.21 0.21
Power Consumption
★
(Rated)W40354545
Power Factor
★
% 95.7 96.0 97.4 97.4
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 298×1,050×190
Package Dimensions (W×D×H) mm 1,183×367×289
Weight kg 12
Gross Weight kg 16
Operation Sound dBA
H44424544
M40384139
L35333734
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
Drawing No. 3D028409A 3D028410
