Si18-201 Specifications
Specifications 49
★
Refer to Engineering Data Book.
"
7.1kW Class
60Hz 220V
Model
FTXD71JVET
Cooling Heating
Rating Capacity kW 7.1 8.5
Front Panel Color Almond White
Air Flow
Rates
m³/min
H 14.3 18.1
M 12.3 14.9
L 10.4 11.7
cfm
H 505 639
M 434 526
L 367 413
Fan
Type Cross Flow Fan
Motor Output W 54
Speed Steps 5 Steps and Auto
Air Filter Removal / Washable / Mildew Proof
Running Current
★
(Rated) A 0.23 0.23
Power Consumption
★
(Rated) W 50 50
Power Factor
★
% 98.8 98.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 298×1,050×190
Package Dimensions (W×D×H) mm 1,183×367×289
Weight kg 12
Gross Weight kg 16
Operation Sound dBA
H46 46
M42 40
L37 34
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
9.5
Gas mm
φ
15.9
Drain mm
φ
18.0
Drawing No. 3D028411
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
To Next Page
