106 Spyder 3 CL User's Manual
03-032-20008-00 DALSA
Item (when
programmable
configuration the options
are separated with a | )
S3-10-01k40 S3-20-01k40 S3-10-02k40 S3-20-02k40
Imager Rows<number of
active rows, Y> Line
Scan/TDI are defined as 1
1 1 1 1
Number of CCD Taps
<1,2,3…..>
1 2 1 2
Sensor Tap Clock Rate <xx
MHz>
40 40 40 40
Camera Standard <NTSC,
PAL, VS, VW, MW>
VS VS VS VS
Variable Window
<Column Start, Column End,
Row Start, Row End>
(0,0,0,0)
All zeros indicates
an unsupported
feature
(0,0,0,0)
All zeros
indicates an
unsupported
feature
(0,0,0,0)
All zeros
indicates an
unsupported
feature
(0,0,0,0)
All zeros indicates an
unsupported feature
Multiple Window
Number of Windows (Column
Start 1, Column End 1, Row
Start 1, Row End 1) (Column
Start 2, Column End 2,...)
0, (0,0,0,0)
All zeros indicates
an unsupported
feature
0, (0,0,0,0)
All zeros
indicates an
unsupported
feature
0, (0,0,0,0)
All zeros
indicates an
unsupported
feature
0, (0,0,0,0)
All zeros indicates an
unsupported feature
Number of Camera
Configurations<1,2,3,…>
2 2 2 2
Configuration Definition
Cx= HDW, Number of Output
Taps, Bit Width, Number of
Processing Nodes where
Cx is the configuration ID x is
<1,2,3…>
HDW is <Base, Medium,
Full>
Number of Output Taps is
<1,2,3…>
Bit width is <8, 10, 12…>
Number Processing Nodes is
<1 or 2>
C1 = Base, 1, 8, 1
C2 = Base, 1, 12, 1
C1 = Base, 2, 8, 1
C2 = Base, 2, 12, 1
C1 = Base, 1, 8, 1
C2 = Base, 1, 12, 1
C1 = Base, 2, 8,
1
C2 = Base, 2, 12,
1
