Dalsa S3-10-01k40-R User Manual

Spyder 3 CL User's Manual 107
DALSA 03-032-20008-00
Item (when
programmable
configuration the options
are separated with a | )
S3-10-01k40 S3-20-01k40 S3-10-02k40 S3-20-02k40
Tap Reconstruction
In some configurations the
reconstruction may change.
C0 is the default output
format and must be listed.
Output configurations that
don’t conform are listed
separately.
<Cx,Tn (Column Start,
Column End, Column
Increment, Row Start, Row
End, Row Increment>
Horizontal
mirroring is
supported. Mirror
“on” changes the
following
unmirrored values
to:
• The sign of the
column
increment is
inverted.
• Column Start
becomes the
Column End
value
• Column End
becomes the
Column Start
value
Direction left to
right readout
C0, T1 (1, 1024, 1, 1,
1, 1)
Horizontal
mirroring is
supported. Mirror
“on” changes the
following
unmirrored
values to:
• The sign of
the column
increment is
inverted.
• Column Start
becomes the
Column End
value
• Column End
becomes the
Column Start
value
Direction left to
right readout
C0, T1 (1, 512, 1,
1, 1, 1)
C0, T2 (513, 1024,
1, 1, 1, 1)
Horizontal
mirroring is
supported.
Mirror “on”
changes the
following
unmirrored
values to:
• The sign of
the column
increment is
inverted.
• Column Start
becomes the
Column End
value
• Column End
becomes the
Column Start
value
Direction left to
right readout
C0, T1 (1, 2048, 1,
1, 1, 1)
Horizontal mirroring is
supported. Mirror “on”
changes the following
unmirrored values to:
• The sign of the
column increment is
inverted.
• Column Start
becomes the Column
End value
• Column End
becomes the Column
Start value
Direction left to right
readout
C0, T1 (1, 1024, 1, 1, 1, 1)
C0, T2 (1025, 2048, 1, 1, 1,
1)
Camera Color
<Hybrid, Mono, Pattern,
Solid>
Mono Mono Mono Mono
RGB Pattern Size
< (T1, Columns*Rows) (T2,
Columns*Rows) (T3,
Columns*Rows….>
(T0, 1*1) where 0 is
reserved for the
default case and
individual taps
don’t need to be
articulated
(T0, 1*1) where 0
is reserved for the
default case and
individual taps
don’t need to be
articulated
(T0, 1*1) where 0
is reserved for
the default case
and individual
taps don’t need
to be articulated
(T0, 1*1) where 0 is
reserved for the default
case and individual taps
don’t need to be
articulated
Color Definition
(Column, Row, Color)
Where color is R,G,B
T0 = (1, 1, M) where
0 is reserved for the
default case and
individual taps
don’t need to be
defined
T0 = (1, 1, M)
where 0 is
reserved for the
default case and
individual taps
don’t need to be
defined
T0 = (1, 1, M)
where 0 is
reserved for the
default case and
individual taps
don’t need to be
defined
T0 = (1, 1, M) where 0 is
reserved for the default
case and individual taps
don’t need to be defined
Row Color Offset
<0,1,2,3…>
0 0 0 0
Column Color Offset
<0,1,2,3…>
0 0 0 0
Row Binning Factor <1,2,3 or
1|2|3>
1 1 1 1
Column Binning Factor
<1,2,3 or 1|2|3>
1| 2 1| 2 1| 2 1| 2
