108 Spyder 3 CL User's Manual
03-032-20008-00 DALSA
Item (when
programmable
configuration the options
are separated with a | )
S3-10-01k40 S3-20-01k40 S3-10-02k40 S3-20-02k40
Pretrigger Pixels <0,1,2…or
0..15>
0 0 0 0
Pretrigger Lines <0,1,2.. or
0..15>
0 0 0 0
Frame Time Minimum <xx
µs>
14.7 27.78 27.78 54.05
Frame Time Maximum <xx
µs>
3333 3333 3333 3333
Internal Line/Frame Time
Resolution
<xx ns> 0 if not applicable
25 25 25 25
Pixel Reset Pulse Minimum
Width
<xx ns> 0 if not applicable
3000 3000 3000 3000
Internal Pixel Reset Time
Resolution
<xx ns> 0 if not applicable
25 25 25 25
Pixel Reset to Exsync Hold
time <xx ns>
TBD
BAUD Rate <9600….> 9600, 19200, 57600,
115200
9600, 19200,
57600, 115200
9600, 19200,
57600, 115200
9600, 19200, 57600, 115200
CC1 <Exsync> EXSYNC EXSYNC EXSYNC EXSYNC
CC2 <Spare> PRIN PRIN PRIN PRIN
CC3 <Forward, Spare> Forward/Reverse Forward/Reverse Forward/Reverse Forward/Reverse
CC4 <Spare> Spare Spare Spare Spare
DVAL out <Strobe Valid,
Alternate>
Strobe Valid Strobe Valid Strobe Valid Strobe Valid
Spare out <Spare> Spare Spare Spare Spare
