3.4.2.2 Grounding IP20 Enclosures
The frequency converter can be grounded using conduit or
shielded cable. For grounding of the power connections,
use the dedicated grounding points as shown in
Illustration 3.5.
Illustration 3.5 Grounding Points for IP20 (Chassis) Enclosures
3.4.2.3
Grounding IP21/54 Enclosures
The frequency converter can be grounded using conduit or
shielded cable. For grounding of the power connections,
use the dedicated grounding points as shown in
Illustration 3.6.
Illustration 3.6 Grounding for IP21/54 Enclosures.
Installation Operating Instructions
MG16D302 Danfoss A/S © Rev. 06/2014 All rights reserved. 15
