Danfoss FC 102 Operating Instructions

6 Programming
6.1 Introduction
The frequency converter is programmed for its application
functions using parameters. Parameters are accessed by
pressing either [Quick Menu] or [Main Menu] on the LCP.
(See chapter 5.1 Local Control Panel for details on using the
LCP function keys). Parameters may also be accessed via a
PC using the MCT 10 Set-up Software (see
chapter 6.6.1 Remote Programming with MCT 10 Set-up
Software).
The Quick Menu is intended for initial start-up (Q2-** Quick
Set-up) and detailed instructions for common frequency
converter applications (Q3-** Function Set-up). Step-by-step
instructions are provided. These instructions enable the
user to walk through the parameters used for
programming applications in their proper sequence. Data
entered in a parameter can change the options available in
the parameters following that entry. The Quick Menu
presents easy guidelines for getting most systems up and
running.
The Main Menu accesses all parameters and allows for
advanced frequency converter applications.
6.2
Programming Example
Here is an example for programming the frequency
converter for a common application in open loop using
the quick menu.
•
This procedure programs the frequency converter
to receive a 0-10 V DC analog control signal on
input terminal 53
•
The frequency converter will respond by
providing 20-50 Hz output to the motor propor-
tional to the input signal (0-10 V DC=20-50 Hz)
This is a common pump or fan application.
Press [Quick Menu] and select the following parameters
using the navigation keys to scroll to the titles and press
[OK] after each action.
1.
Q3 Function Setups
2.
Parameter Data Set
130BT112.10
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
69.3% 5.20A 1(1)
Quick Menus
Illustration 6.1 Q3 Function Setups
3.
Q3-2 Open Loop Settings
Q3
130BT760.10
Q3-1 General Settings
Q3-2 Open Loop Settings
Q3-3 Closed Loop Settings
Q3-4 Application Settings
28.4% 2.05A 1(1)
Function Setups
Illustration 6.2 Q3-2 Open Loop Settings
4.
Q3-21 Analog Reference
Q3-2
130BT761.10
Q3-20 Digital Reference
Q3-21 Analog Reference
14.7% 0.00A 1(1)
Open Loop Settings
Illustration 6.3 Q3-21 Analog Reference
5.
3-02 Minimum Reference. Set minimum internal
frequency converter reference to 0 Hz. (This sets
the minimum frequency converter speed at 0 Hz).
Q3-21
130BT762.10
3-02 Minimum Reference
0.000 Hz
14.7% 0.00A 1(1)
Analog Reference
Illustration 6.4 3-02 Minimum Reference
Programming Operating Instructions
44 Danfoss A/S © Rev. 06/2014 All rights reserved. MG16D302
