1.2 Purpose of the Manual
This manual provides detailed information for the instal-
lation and start-up of the frequency converter.
Chapter 3 Installation provides requirements for mechanical
and electrical installation, including:
•
Input
•
Motor
•
Control wiring
•
Serial communication wiring
•
Control terminal functions
Chapter 4 Start Up and Commissioning provides detailed
procedures for:
•
Start-up
•
Basic operational programming
•
Functional testing
The remaining chapters provide supplementary details.
These details include:
•
User interface
•
Detailed programming
•
Application examples
•
Start-up
•
Troubleshooting
•
Specifications
VLT
®
is a registered trademark.
1.3
Additional Resources
Other resources are available to understand advanced
frequency converter functions and programming.
•
The VLT
®
Programming Guide provides greater
detail on working with parameters and many
application examples.
•
The VLT
®
Design Guide is intended to provide
detailed capabilities and functionality to design
motor control systems.
•
Supplemental publications and manuals are
available from Danfoss.
See www.danfoss.com/BusinessAreas/DrivesSo-
lutions/Documentations/VLT+Technical
+Documentation.htm for listings.
•
Optional equipment is available that may change
some of the procedures described. Reference the
instructions supplied with those options for
specific requirements. Contact the local Danfoss
supplier or visit the Danfoss website:
www.danfoss.com/BusinessAreas/DrivesSolutions/
Documentations/VLT+Technical+Documen-
tation.htm, for downloads or additional
information.
1.4 Product Overview
A frequency converter is an electronic motor controller
that converts DC into a variable AC waveform output. The
frequency and voltage of the output are regulated to
control the motor speed or torque. The frequency
converter can vary the speed of the motor in response to
system feedback, such as position sensors on a conveyor
belt. The frequency converter can also regulate the motor
by responding to remote commands from external
controllers.
The frequency converter offers many control, monitoring
and efficiency functions such as:
•
Monitoring the system and motor status
•
Issuing warnings or alarms for fault conditions
•
Starting and stopping the motor
•
Optimising energy efficiency
Operation and monitoring functions are available as status
indications to an outside control system or serial communi-
cation network.
