Danfoss FC 102 Operating Instructions

11 Specifications
11.1 Power-dependent Specifications
N110 N132 N160 N200 N250 N315
Normal Load* NO NO NO NO NO NO
Typical Shaft output at 400 V [kW] 110 132 160 200 250 315
Typical Shaft output at 460 V [hp] 150 200 250 300 350 450
Typical Shaft ouptut at 480 V [kW] 132 160 200 250 315 355
Enclosure IP21 D1h D1h D1h D2h D2h D2h
Enclosure IP54 D1h D1h D1h D2h D2h D2h
Enclosure IP20 D3h D3h D3h D4h D4h D4h
Output current
Continuous (at 400 V) [A] 212 260 315 395 480 588
Intermittent (60 s overload) (at 400
V)[A]
233 286 347 435 528 647
Continuous (at 460/500 V) [A] 190 240 302 361 443 535
Intermittent (60 s overload) (at
460/500 V) [kVA]
209 264 332 397 487 588
Continuous kVA (at 400 V) [kVA] 147 180 218 274 333 407
Continuous kVA (at 460 V) [kVA] 151 191 241 288 353 426
Max. Input current
Continuous (at 400 V) [A] 204 251 304 381 463 567
Continuous (at 460/500 V) [A] 183 231 291 348 427 516
Max. cable size: mains, motor,
brake and load share mm (AWG)]
2 x95 (2x3/0) 2x185 (2x350)
Max. external mains fuses [A] 315 350 400 550 630 800
Estimated power loss at 400 V [W] 2555 2949 3764 4109 5129 6663
Estimated power loss at 460 V [W] 2257 2719 3622 3561 4558 5703
Weight, enclosure IP21, IP54 kg
(lbs.)
62 (135) 125 (275)
Weight, enclosure IP20 kg (lbs.) 62 (135) 125 (275)
Efficiency 0.98
Output frequency 0-590 Hz
*Normal overload=110% current for 60 s
Table 11.1 Mains Supply 3x380-480 V AC
Specifications Operating Instructions
