7.3 Connection Examples for Control of Motor with External Signal Provider
58
7.3.1 Start/Stop 58
7.3.2 Pulse Start/Stop 58
7.3.3 Speed Up/Down 58
7.3.4 Potentiometer Reference 59
8 Status Messages
60
8.1 Status Display
60
8.2 Status Message Definitions Table
60
9 Warnings and Alarms
63
9.1 System Monitoring
63
9.2 Warning and Alarm Types
63
9.2.1 Warnings 63
9.2.2 Alarm Trip 63
9.2.3 Alarm Trip-lock 63
9.3 Warning and Alarm Displays
63
9.4 Warning and Alarm Definitions
64
9.5 Fault Messages
66
10 Basic Troubleshooting
73
11 Specifications
76
11.1 Power-dependent Specifications
76
11.2 General Technical Data
79
11.3 Fuse Tables
83
11.3.1 Protection 83
11.3.2 Fuse Selection 83
11.3.3 Short Circuit Current Rating (SCCR) 84
11.3.4 Connection Tightening Torques 84
Index
86
Contents Operating Instructions
MG16D302 Danfoss A/S © Rev. 06/2014 All rights reserved. 3
