Danfoss FC 102 Operating Instructions

Frame Size Terminal Torque Bolt
size
D1h/D3h/D5h/D6h Mains
Motor
Load sharing
Regen
19-40 Nm
(168-354 in-lbs)
M10
Earth (Ground)
Brake
8.5-20.5 Nm
(75-181 in-lbs)
M8
D2h/D4h/D7h/D8h Mains
Motor
Regen
Load sharing
Earth (ground)
19-40 Nm
(168-354 in-lbs)
M10
Brake 8.5-20.5 Nm
(75-181 in-lbs)
M8
Table 11.10 Torque for Terminals
