Danfoss FC 102

Recommended max. fuse
Power
[kW]
Bussmann
Type JFHR2
2)
Littel fuse
JFHR2
Ferraz-
Shawmut
JFHR2
4)
Ferraz-
Shawmut
J
1.1 FWX-10 - - HSJ-10
1.5 FWX-15 - - HSJ-15
2.2 FWX-20 - - HSJ-20
3.0 FWX-25 - - HSJ-25
3.7 FWX-30 - - HSJ-30
5.5-7.5 FWX-50 - - HSJ-50
11 FWX-60 - - HSJ-60
15-18.5 FWX-80 - - HSJ-80
22 FWX-125 - - HSJ-125
30 FWX-150 L25S-150 A25X-150 HSJ-150
37 FWX-200 L25S-200 A25X-200 HSJ-200
45 FWX-250 L25S-250 A25X-250 HSJ-250
Table 6.25 200-240 V, Enclosure Types A, B and C
1) KTS-fuses from Bussmann may substitute KTN for 240 V frequency converters.
2) FWH-fuses from Bussmann may substitute FWX for 240 V frequency converters.
3) A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V frequency converters.
4) A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V frequency converters.
Recommended max. fuse
Power
[kW]
Bussmann
Type RK1
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
1.1 KTS-R-6 JKS-6 JJS-6 FNQ-R-6 KTK-R-6 LP-CC-6
1.5-2.2 KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
3 KTS-R-15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
4 KTS-R-20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
5.5 KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
7.5 KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
11-15 KTS-R-40 JKS-40 JJS-40 - - -
18 KTS-R-50 JKS-50 JJS-50 - - -
22 KTS-R-60 JKS-60 JJS-60 - - -
30 KTS-R-80 JKS-80 JJS-80 - - -
37 KTS-R-100 JKS-100 JJS-100 - - -
45 KTS-R-125 JKS-125 JJS-125 - - -
55 KTS-R-150 JKS-150 JJS-150 - - -
75 KTS-R-200 JKS-200 JJS-200 - - -
90 KTS-R-250 JKS-250 JJS-250 - - -
Table 6.26 380-480 V, Enclosure Types A, B and C
Electrical Installation Design Guide
100 Danfoss A/S © Rev. 06/2014 All rights reserved. MG11BC02
66
