1)
Ferraz-Shawmut A50QS fuses may substitute for A50P fuses.
Recommended max. fuse
Power
[kW]
Bussmann
Type RK1
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
1.1 KTS-R-5 JKS-5 JJS-6 FNQ-R-5 KTK-R-5 LP-CC-5
1.5-2.2 KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
3 KTS-R15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
4 KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
5.5 KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
7.5 KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
11-15 KTS-R-35 JKS-35 JJS-35 - - -
18 KTS-R-45 JKS-45 JJS-45 - - -
22 KTS-R-50 JKS-50 JJS-50 - - -
30 KTS-R-60 JKS-60 JJS-60 - - -
37 KTS-R-80 JKS-80 JJS-80 - - -
45 KTS-R-100 JKS-100 JJS-100 - - -
55 KTS-R-125 JKS-125 JJS-125 - - -
75 KTS-R-150 JKS-150 JJS-150 - - -
90 KTS-R-175 JKS-175 JJS-175 - - -
Table 6.29 525-600 V, Enclosure Types A, B and C
Recommended max. fuse
Power [kW]
SIBA
Type RK1
Littel fuse
Type RK1
Ferraz-
Shawmut
Type RK1
Ferraz-
Shawmut
J
1.1 5017906-005 KLS-R-005 A6K-5-R HSJ-6
1.5-2.2 5017906-010 KLS-R-010 A6K-10-R HSJ-10
3 5017906-016 KLS-R-015 A6K-15-R HSJ-15
4 5017906-020 KLS-R-020 A6K-20-R HSJ-20
5.5 5017906-025 KLS-R-025 A6K-25-R HSJ-25
7.5 5017906-030 KLS-R-030 A6K-30-R HSJ-30
11-15 5014006-040 KLS-R-035 A6K-35-R HSJ-35
18 5014006-050 KLS-R-045 A6K-45-R HSJ-45
22 5014006-050 KLS-R-050 A6K-50-R HSJ-50
30 5014006-063 KLS-R-060 A6K-60-R HSJ-60
37 5014006-080 KLS-R-075 A6K-80-R HSJ-80
45 5014006-100 KLS-R-100 A6K-100-R HSJ-100
55 2028220-125 KLS-R-125 A6K-125-R HSJ-125
75 2028220-150 KLS-R-150 A6K-150-R HSJ-150
90 2028220-200 KLS-R-175 A6K-175-R HSJ-175
Table 6.30 525-600 V, Enclosure Types A, B and C
1)
170M fuses shown from Bussmann use the -/80 visual indicator. –TN/80 Type T, -/110 or TN/110 Type T indicator
fuses of the same size and amperage may be substituted.
Electrical Installation
Design Guide
102 Danfoss A/S © Rev. 06/2014 All rights reserved. MG11BC02
