Danfoss FC 102 Design Guide

Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
30 240 0.556 0.650 0.935
100 240 0.592 0.594 0.807
150 240 0.708 0.575 0.669
Table 9.14 Frequency converter, P15K, T2
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
36 240 0.244 0.608 1.993
136 240 0.568 0.580 0.832
150 240 0.720 0.574 0.661
Table 9.15 Frequency converter, P18K, T2
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
36 240 0.244 0.608 1.993
136 240 0.560 0.580 0.832
150 240 0.720 0.574 0.661
Table 9.16 Frequency converter, P22K, T2
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
15 240 0.194 0.626 2.581
50 240 0.252 0.574 1.929
150 240 0.444 0.538 0.977
Table 9.17 Frequency converter, P30K, T2
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
30 240 0.300 0.598 1.593
100 240 0.536 0.566 0.843
150 240 0.776 0.546 0.559
Table 9.18 Frequency converter, P37K, T2
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
30 240 0.300 0.598 1.593
100 240 0.536 0.566 0.843
150 240 0.776 0.546 0.559
Table 9.19 Frequency converter, P45K, T2
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
5 400 0.640 0.690 0.862
50 400 0.470 0.985 0.985
150 400 0.760 1.045 0.947
Table 9.20 Frequency converter, P1K5, T4
