Danfoss FC 102

Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
5 400 0.172 0.890 4.156
50 400 0.310 2.564
150 400 0.370 1.190 1.770
Table 9.21 Frequency converter, P4K0, T4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
5 400 0.04755 0.739 8.035
50 400 0.207 1.040 4.548
150 400 0.6742 1.030 2.828
Table 9.22 Frequency converter, P7K5, T4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
15 400 0.408 0.718 1.402
100 400 0.364 1.050 2.376
150 400 0.400 0.980 2.000
Table 9.23 Frequency converter, P11K, T4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
36 400 0.422 1.060 2.014
100 400 0.464 0.900 1.616
150 400 0.896 1.000 0.915
Table 9.24 Frequency converter, P15K, T4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
36 400 0.344 1.040 2.442
100 400 1.000 1.190 0.950
150 400 1.400 1.040 0.596
Table 9.25 Frequency converter, P18K, T4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
36 400 0.232 0.950 3.534
100 400 0.410 0.980 1.927
150 400 0.430 0.970 1.860
Table 9.26 Frequency converter, P22K, T4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
15 400 0.271 1.000 3.100
100 400 0.440 1.000 1.818
150 400 0.520 0.990 1.510
Table 9.27 Frequency converter, P30K, T4
General Specifications and ...
Design Guide
MG11BC02 Danfoss A/S © Rev. 06/2014 All rights reserved. 163
9 9
