Danfoss FC 102

294
(11.6)
163
(6.4)
130BF667.10
262
(10.3)
1
3
19 (0.7) 2X 268 (10.6)
2X 220
(8.6)
160
(6.3)
2
1 RFI shield termination (standard with RFI option)
2 Cable/EMC clamp
3 Gland plate
Illustration 9.17 RFI Shield Termination and Gland Plate Dimensions for E4h
