5.9 Pre-start Check List
Before completing installation of the unit, inspect the entire installation as detailed in Table 5.4. Check and mark the items
when completed.
Inspect for Description
☑
Auxiliary equipment
•
Look for auxiliary equipment, switches, disconnects, or input fuses/circuit breakers that reside on the input
power side of the drive or output side to the motor. Ensure that they are ready for full-speed operation.
•
Check function and installation of any sensors used for feedback to the drive.
•
Remove any power factor correction caps on motor.
•
Adjust any power factor correction caps on the mains side and ensure that they are dampened.
Cable routing
•
Ensure that motor wiring, brake wiring (if equipped), and control wiring are separated or shielded, or in 3
separate metallic conduits for high-frequency interference isolation.
Control wiring
•
Check for broken or damaged wires and loose connections.
•
Check that control wiring is isolated from high-power wiring for noise immunity.
•
Check the voltage source of the signals, if necessary.
•
The use of shielded cable or twisted pair is recommended. Ensure that the shield is terminated correctly.
Cooling clearance
•
Measure top clearance for adequate airow for cooling, see chapter 4.5.1 Installation and Cooling
Requirements.
Ambient conditions
•
Check that requirements for ambient conditions are met. See chapter 9.4 Ambient Conditions.
Fusing and circuit
breakers
•
Check for proper fusing or circuit breakers.
•
Check that all fuses are inserted rmly and are in operational condition and that all circuit breakers (if
used) are in the open position.
Grounding
•
Check for good ground connections that are tight and free of oxidation.
•
Grounding to conduit, or mounting the back panel to a metal surface, is not a suitable grounding.
Input and output
power wiring
•
Check for loose connections.
•
Check that motor and mains are in separate conduit or separated shielded cables.
Panel interior
•
Inspect that the unit interior is free of dirt, metal chips, moisture, and corrosion.
•
Verify that all installation tools have been removed from unit interior.
•
For E3h and E4h enclosures, ensure that the unit is mounted on an unpainted, metal surface.
Switches
•
Ensure that all switch and disconnect settings are in the proper positions.
Vibration
•
Check that the unit is mounted solidly, or that shock mounts are used, if necessary.
•
Check for an unusual amount of vibration.
Table 5.4 Pre-start Check List
CAUTION
POTENTIAL HAZARD IN THE EVENT OF INTERNAL FAILURE
If the drive is not properly secured with covers, personal injury can occur.
•
Before applying power, ensure all safety covers (door and panels) are in place and securely fastened. Refer to
chapter 9.10.1 Fastener Torque Ratings.
Electrical Installation VLT® HVAC Drive FC 102
46 Danfoss A/S © 01/2017 All rights reserved. MG16O102
