5.7 Terminal Dimensions
5.7.1 E1h Terminal Dimensions
130BF683.10
6X 613 (24.1)
383 (15.1) 472 (18.6) 423 (16.7)
165 (6.5)
0 (0.0)
101 (4.0)
82 (3.2)
721 (28.4)
0 (0.0)
1
2
3
4
200 (7.9)
515 (20.3)
485 (19.1)
248 (9.8)
241 (9.5) 171 (6.7)
414 (16.3)
361 (14.2) 331 (13.0)
501 (19.7)
497 (19.6) 431 (17.0)
512 (20.2)
5
1 Mains terminals 3 Motor terminals
2 Brake or regeneration terminals 4 Ground terminals, M10 nut
Illustration 5.6 E1h Terminal Dimensions (Front View)
Electrical Installation Operating Guide
MG16O102 Danfoss A/S © 01/2017 All rights reserved. 31
5 5
