D. Indicator lights
Indicator lights are used to identify the drive status and to
provide a visual notication of warning or fault conditions.
Callout Indicator Indicator
light
Function
D1 On Green Activates when the drive receives
power from the mains voltage or
a 24 V external supply.
D2 Warn. Yellow Activates when warning
conditions are active. Text
appears in the display area
identifying the problem.
D3 Alarm Red Activates during a fault
condition. Text appears in the
display area identifying the
problem.
Table 3.5 LCP Indicator Lights
E. Operation keys and reset
The operation keys are found toward the bottom of the
local control panel.
Callout Key Function
E1 [Hand On] Starts the drive in local control. An
external stop signal by control input or
serial communication overrides the local
[Hand On].
E2 O Stops the motor but does not remove
power to the drive.
E3 Auto On Puts the system in remote operational
mode so it can respond to an external
start command by control terminals or
serial communication.
E4 Reset Resets the drive manually after a fault has
been cleared.
Table 3.6 LCP Operation Keys and Reset
Product Overview Operating Guide
MG16O102 Danfoss A/S © 01/2017 All rights reserved. 11
3 3
