130BF661.10
0 (0.0)
0 (0.0)
160 (6.3)
0 (0.0)
373 (14.7) 287 (11.3) 287 (11.3)
160 (6.3)
0 (0.0)
184
(7.2)
184
(7.2)
A
5X 14 (0.5)
44 (1.8)
0 (0.0)
36 (1.4)
18 (0.7)
0 (0.0)
84 (3.3) 42 (1.7)
A
Illustration 5.11 E3h Mains, Motor, and Ground Terminal Dimensions (Side Views)
Electrical Installation VLT® HVAC Drive FC 102
36 Danfoss A/S © 01/2017 All rights reserved. MG16O102
