9.8.3 E3h Exterior Dimensions
130BF656.10
1578
(62.1)
1537
(60.5)
1348
(53.1)
13 (0.5)
3X
506
(19.9)
30
(1.2)
13 (0.5)
10 (0.4)
10 (0.4)
15 (0.6)
A
A
Illustration 9.10 Front View of E3h
