FC 300 Operating Instructions
How to Programme
" 1-** Load/Motor
Par.
No.
#
Parameter description Default value
(SR - Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
1-0* General Settings
1-00 Configuration Mode - All set-ups TRUE - Uint8
1-01 Motor Control Principle - All set-ups FALSE - Uint8
1-02 Flux Motor Feedback Source [1] 24V en coder All set-ups x FALSE - Uint8
1-03 Torque Characteristics [0] Constant torque All set-ups TRUE - Uint8
1-04 Overload Mode [0] High torque All set-ups FAL SE - Uint8
1-05 Local Mode Configuration [2] Mode as par 1-00 All set-ups TRUE - Uint8
1-1* Motor Selection
1-10 Motor Construction [0] Asynchron All set-ups FALSE - Uint8
1-2* Motor Data
1-20 Motor Power [kW] SR All set-ups FAL SE 1 Uint32
1-21 Motor Power [HP] SR All set-ups FALSE -2 Uint32
1-22 Motor Voltage SR All set-ups FALSE 0 Uint16
1-23 Motor Frequency SR All set-ups FALSE 0 Uint16
1-24 Motor Current SR All set-ups FALSE - 2 Uint32
1-25 Motor Nominal Speed SR All set-ups FALSE 67 Uint16
1-26 Motor Cont. Rated Torque SR All set-ups FALSE -1 Uint32
1-29 Automatic Motor Adaptation (AMA) [0] Off All set-ups FALSE - Uint8
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs) SR All set-ups FALSE -4 Uint32
1-31 Rotor Resistance (Rr) SR All set-up s FALSE -4 Uint32
1-33 Stator Leakage Reactance (X1) SR All set-ups FALSE -4 U int32
1-34 Rotor Leakage Reactance (X2) SR All set-ups FALSE -4 Uint32
1-35 Main Reactance (Xh) SR All set-ups FALSE -4 Uint32
1-36 Iron Loss Resistance (Rfe) SR All set-ups FALSE -3 Uint32
1-37 d-axis Inductance (Ld) SR All set-ups x FALSE -4 Int32
1-39 Motor Poles SR All set-ups FAL SE 0 Uint8
1-40 Back EMF at 1000 RPM SR All set-ups x FALSE 0 Uint16
1-41 Motor Angle Offset 0 All set-ups FALSE 0 Int16
1-5* Load Indep. Setting
1-50 Motor Magnetisation at Zero Speed 100 % All set-ups TRUE 0 Uint16
1-51
Min Speed Normal Magnetising
[RPM] SR All set-ups TRUE 67 Uint16
1-52 Min Speed Normal Magnetising [Hz] SR All set-ups TRUE -1 Uint16
1-53 Model Shift Frequency SR All set-ups x FAL SE - 1 U int16
1-55 U/f Characteristic - U SR All set-ups TRUE -1 Uint16
1-56 U/f Characteristic - F SR All set-ups TRUE -1 Uint16
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation 100 % All set-ups TRUE 0 Int16
1-61 High Speed Load Compensation 100 % All set-ups TRUE 0 Int16
1-62 Slip Compensation SR All set-ups TRUE 0 Int16
1-63 Slip Compensation Time Constant 0.10 s All set-ups TRUE -2 Uint16
1-64 Resonance Dampening 100 % All set-ups TRUE 0 Uint16
1-65
Resonance Dampening Time
Constant 5 ms All set-ups TRUE -3 Uint8
1-66 Min. Current at Low Speed 100 % All set-ups x TRUE 0 Uint8
1-67 Load Type [0] Passive load All set-ups x TRUE - Uint8
1-68 Minimum Inertia SR All set-ups x FALSE -4 Uint32
1-69 Maximum Inertia SR All set-ups x FALSE -4 Uint32
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
42
MG.33.A7.02 - VLT is a registered Danfoss trademark
