Danfoss FC 300 Operating Instruction

FC 300 Operating Instructions
How to Programme
" 0-** Op eration/Display
Par.
No.
#
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
0-0* Basic Settings
0-01 Language [0] English 1 set-up TRUE - Uint8
0-02 Motor Speed Unit [0] RPM 2 set-ups FALSE - Uint8
0-03 Regional Settings [0] International 2 set-ups FALSE - Uint8
0-04
Operating State at Power-up
(Hand)
[1] Forced stop,
ref=old All set-ups TRU E - Uint8
0-1* Set-up Operations
0-10 Active Set-up [1] Set-up 1 1 set-up TRUE - Uint8
0-11 Edit Set-up [1] Set-up 1 All set-ups TRUE - Uint8
0-12 This Set-up Linked to [0] Not linked All set-ups FAL SE - Uint8
0-13 Readout: Linked Set-ups 0 All set-ups FALSE 0 Uint16
0-14 Readout: Edit Set-ups / Channel 0 All set-ups TRUE 0 Int32
0-2* LCP D isplay
0-20 Display Line 1.1 Small Speed [R PM] All set-ups TRUE - Uint16
0-21 Display Line 1.2 Small Motor current [A] All set-ups TRUE - Uint16
0-22 Display Line 1.3 Small Power [kW] All set-ups TRUE - Uint16
0-23 Display Line 2 Large Frequency [Hz] All set-ups TRU E - Uint16
0-24 Display Line 3 Large Reference [%] All set-ups TRUE - Uint16
0-25 My Personal Menu - 1 set-up TRUE 0 Uint16
0-3* LCP Custom Readout
0-30 Unit for User-defined Readout [0] None All set-ups TRUE - Uint8
0-31 Min Value of User- defined Readout 0 .00 All set-ups TRUE -2 Int32
0-32 Max Value of User-defined Readout 100.00 All set-ups TRUE -2 Int32
0-4* LC P Keypa d
0-40 [Hand on] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-41 [Off] Key on LCP [1] Enabled A ll set-ups TRUE - Uint8
0-42 [Auto on] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-43 [Reset] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-5* Copy/Save
0-50 LCP Copy [0] No copy All set-ups FALSE - Uint8
0-51 Set-up Copy [0] No copy All set-ups FAL SE - Uint8
0-6* Password
0-60 Main Menu Pa ssword 100 1 set-up TRUE 0 Uint16
0-61 Access to Main Menu w / o Password [0] Full ac cess 1 set-up TRUE - Uint8
0-65 Quick Menu Password 200 1 set-up TRUE 0 Uint16
0-66 Access to Quick Menu w/o Password [0] Full ac ces s 1 set-up TRU E - Uint8
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
41
MG.33.A7.02 - VLT is a registered Danfoss trademark
