FC 300 Operating Instructions
How to Programme
Par.
No.
#
Parameter description Default value
(SR = Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
1-7* Sta rt Adjustments
1-71 Start Delay 0.0 s All set-ups TRUE -1 Uint8
1-72 Start Function [2] Coast/delay time All set-ups TRUE - Uint8
1-73 Flying Start [RPM] [0] Disabled All set-ups FAL SE - Uint8
1-74 Start Speed [RPM] SR All set-ups TRUE 67 Uint16
1-75 Start Speed [Hz] SR All set-ups TRUE -1 Uint16
1-76 Start Current 0.00 A All set-ups TRUE -2 Uint32
1-8* St op Adjustments
1-80 Function at Stop [0] Coast All set-ups TRUE - Uint8
1-81
Min Speed for Function at Stop
[RPM] SR All set-ups TRUE 67 Uint16
1-82 Min Speed for Function at Stop [Hz] SR All set-ups TRUE -1 Uint16
1-83 Precise Stop Function [0] Precise ramp stop All set-ups FALSE - Uint8
1-84 Precise Stop Counter Value 100000 All set-ups TRUE 0 Uint32
1-85
Precise Stop Speed Compensation
Delay 10 ms All set-ups TRUE -3 Uint8
1-9* M o t or Temperature
1-90 Motor Thermal Protection [0] No protection All set-ups TRUE - Uint8
1-91 Motor External Fan [0] N o All set-ups TRUE - Uint16
1-93 Thermistor Resource [0] None All set-ups TRUE - Uint8
1-95 KTY Sensor Type [0] KTY Sensor 1 All set-ups x TRUE - Uint8
1-96 KTY Thermistor Resource [0] None All set-ups x TRUE - Uint8
1-97 KTY Threshold level 80 °C 1 set-up x TRUE 100 Int16
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
43
MG.33.A7.02 - VLT is a registered Danfoss trademark
