Danfoss FC 300

FC 300 Operating Instructions
How to Programme
" 2-** Brakes
Par.
No.
#
Parameter description Default value
(SR = Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
2-0* DC-Brake
2-00 DC Hold Current 50 % All set-ups TRUE 0 Uint8
2-01 DC Brake Current 50 % All set-ups TRUE 0 Uint16
2-02 DC Braking Time 10.0 s All set-ups TRUE -1 Uint16
2-03 DC Brake Cut In Speed [RPM] SR All set-ups TRUE 67 Uint16
2-04 DC B rake Cut In Speed [Hz] SR All set-ups TRUE - 1 Uint16
2-1* Brake Energy Funct.
2-10 Brake Function - All set-ups TRUE - Uint8
2-11 Brake Resistor (ohm) SR All set-ups TRUE 0 Uint16
2-12 Brake Power Limit (kW) SR All set-ups TRUE 0 Uint32
2-13 Brake Powe r Monitoring [0] Off All set-ups TRUE - Uint8
2-15 Brake Check [0] Off All set-ups TRUE - Uint8
2-16 AC brake Max. Current 100.0 % All set-ups TRUE -1 Uint32
2-17 Over-voltage Control [0] Disabled All set-ups TRUE - Uint8
2-2* Mechanical Brake
2-20 Release Brake Current SR All set-ups TRUE -2 Uint32
2-21 Activate Brake Speed [RPM] SR All set-ups TRUE 67 Uint16
2-22 Activate Brake Speed [Hz] SR All set-ups TRUE -1 Uint16
2-23 Activate Brake Delay 0.0 s All set-ups TRUE -1 Uint8
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
44
MG.33.A7.02 - VLT is a registered Danfoss trademark
