How to Programme
" 3-** Reference / Ramps
Par.
No.
#
Parameter description Default value
(SR = Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
3-0* Reference Limits
3-00 Reference Range - All set-ups TRUE - Uint8
3-01 Reference/Feedba ck Unit - All set-ups TRUE - Uint8
3-02 Minimum Reference SR All set-ups TRUE -3 Int32
3-03 Maximum Reference SR All set-ups TRUE -3 Int32
3-04 Reference Function [0] Sum All set-ups TRUE - Uint8
3-1* References
3-10 Preset Reference 0.00 % All set-ups TRUE -2 Int16
3-11 Jog Speed [Hz] SR All set-ups TRUE -1 Uint16
3-12 Catch up/slow Down Value 0.00 % All set-ups TRUE -2 Int16
3-13 Reference S ite
[0]LinkedtoHand/
Auto All set-ups TRUE - Uint8
3-14 Preset Relative Reference 0.00 % All set-ups TRUE -2 Int32
3-15 Reference Resource 1 - All set-ups TRUE - Uint8
3-16 Reference Resource 2 - All set-ups TRUE - Uint8
3-17 Reference Resource 3 - All set-ups TRUE - Uint8
3-18
Relative Scaling Reference
Resource [0] No function All set-ups TRUE - Uint8
3-19 Jog Speed [RPM] SR All set-ups TRUE 67 Uint16
3-4* Ramp 1
3-40 Ramp 1 Type [0] Linea r All set-ups TRUE - Uint8
3-41 Ramp 1 Ramp up Time SR All set-ups TRUE -2 Uint32
3-42 Ramp 1 Ramp Down Time SR All set-ups TRUE -2 U int32
3-45
Ramp 1 S-ramp Ratio at Accel.
Start 50 % All set-ups TRUE 0 Uint8
3-46 Ramp 1 S-ramp Ratio at Accel. E nd 50 % All set-ups TRUE 0 Uint8
3-47
Ramp 1 S -ramp Ratio at Decel.
Start 50 % All set-ups TRUE 0 Uint8
3-48 Ramp 1 S-ramp Ratio at Decel. End 50 % All set-ups TRUE 0 Uint8
3-5* Ramp 2
3-50 Ramp 2 Type [0] Linea r All set-ups TRUE - Uint8
3-51 Ramp 2 Ramp up Time SR All set-ups TRUE -2 Uint32
3-52 Ramp 2 Ramp down Time SR All set-ups TRUE -2 Uint32
3-55
Ramp 2 S-ramp Ratio at Accel.
Start 50 % All set-ups TRUE 0 Uint8
3-56 Ramp 2 S-ramp Ratio at Accel. E nd 50 % All set-ups TRUE 0 Uint8
3-57
Ramp 2 S -ramp Ratio at Decel.
Start 50 % All set-ups TRUE 0 Uint8
3-58 Ramp 2 S-ramp Ratio at Decel. End 50 % All set-ups TRUE 0 Uint8
3-6* Ramp 3
3-60 Ramp 3 Type [0] Linea r All set-ups TRUE - Uint8
3-61 Ramp 3 Ramp up Time SR All set-ups TRUE -2 Uint32
3-62 Ramp 3 Ramp down Time SR All set-ups TRUE -2 Uint32
3-65
Ramp 3 S-ramp Ratio at Accel.
Start 50 % All set-ups TRUE 0 Uint8
3-66 Ramp 3 S-ramp Ratio at Accel. E nd 50 % All set-ups TRUE 0 Uint8
3-67
Ramp 3 S -ramp Ratio at Decel.
Start 50 % All set-ups TRUE 0 Uint8
3-68 Ramp 3 S-ramp Ratio at Decel. End 50 % All set-ups TRUE 0 Uint8
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
